| Ramme | FORM™ Alloy | Full Sealed Cartridge Bearings |
| | Press Fit BB | Internal Cable Routing | 2- |
| Bolt ISCG05 Tabs | RIDE-4™ Adjustable |
| Geometry | 2 Position Axle | XS - SM = |
| 140mm | MD - XL = 145mm |
| Gaffel | RockShox Psylo Gold RC 160mm | 27.5 = 37mm |
| Offset | 29 = 42mm Offset |
| Bakdemper | RockShox Deluxe Select+ | Linear XL Air Can | |
| Sealed Bearing Eyelet | 20x8mm F Hardware | XS |
| - SM = 190x45mm | MD - LG - XL = 210x55mm | |
| Size-Specific tune in FAQ |
| Styrelager | FSA ZS56/66 Reach Adjust | 0mm Cups |
| Installed | +/- 5mm Cups Included | Sealed |
| Stainless 36°x45° Bearings | 30.2mm x 41mm |
| x 7.1mm Upper | 40mm x 51.8mm x 7.5mm |
| Lower | 1.5" Crown Race |
| Stem | Rocky Mountain 31.8 AM | 5° Rise | All Sizes = 40mm |
| Styre | Rocky Mountain AM | 780mm Width | 25mm |
| Rise | 9° Backsweep | 5° Upsweep | 31.8 Clamp |
| Holker | Rocky Mountain Lock On Ergo |
| Bremser | Tektro HD-M535 | Shimano Pad Compatible |
| Bremseskiver | Tektro 203mm | Tektro 180mm |
| Girskifter | Shimano Deore 12spd |
| Gir bak | Shimano Deore 12spd |
| Krank | Shimano Deore | 32T | 24mm Spindle |
| | Crankarm Length: XS - SM = 165mm |
| | MD - XL = 170mm |
| Kranklager | Shimano SM-BBMT500 |
| Kassett | Shimano Deore 10-51T 12spd |
| Kjede | Shimano M6100 |
| Nac fram | Shimano TC500 | 15mm Boost |
| Nav bak | Shimano TC500 Boost 148mm |
| Eiker | 2.0 Stainless |
| Felger | Rocky Mountain TR30 | 32H | Tubeless |
| Compatible |
| Dekk | Maxxis Minion DHF 2.5 WT EXO Tubeless |
| Ready | Maxxis Minion DHR II 2.4 WT EXO |
| Tubeless Ready | Tubeless Set Up | Sealant Incl |
| Setepinne | Tranz X +RAD2.0 Adjustable Dropper Post | |
| 30mm Adjustment | Alloy MMX Lever | 30.9mm | |
| XS = 120mm | SM = 150mm | MD = 170mm | LG = |
| 200mm | XL = 230mm |
| Sete | WTB Volt 142 | Steel Rails |
