| Frame |
SMOOTHWALL™ Carbon | Integrated
Display | Smoothlink suspension| RIDE-4™ Adjustable Geometry |Mixed wheel
only| 165mm Travel | SMOOTHWALL™ Carbon | Smoothlink suspension| RIDE-4™
Adjustable Geometry |Mixed wheel only| 165mm Travel Rear Triangle |
| Fork |
RockShox ZEB Ultimate 180mm |
44mm Offset |
| Rear Shock |
Rock Shox Vivid Ultimate |
Linear XL Air Can | 230x65mm | Sealed Bearing Eyelet | 25x8mm F Hardware |
Size-Specific tune in FAQ |
| Headset |
FSA Orbit NO.85 Reach Adjust |
0mm Cups Installed | +/- 5mm Cups Included | Sealed Stainless 36°x45°
Bearings | 30.2mm x 41mm x 6.5mm Upper | 40mm x 51.8mm x 8.0mm Lower |
1.5" Crown Race |
| Stem |
Race Face Turbine | 0° Rise |
All Sizes = 40mm |
| Handlebar |
Race Face ERA | 780mm Width |
40mm Rise | 8° Backsweep | 5° Upsweep | 35mm Clamp |
| Grips |
ODI Elite Pro Lock On |
| Brakes |
Sram Maven Silver Stealth 4
Piston | Metal Pads |
| Rotors |
F: Sram HS2 220mm | R: Sram HS2
200mm |
| Brake Levers |
|
| Shifters |
AXS Pod Controller |
| Front Derailleur |
|
| Rear Derailleur |
Sram X0 Eagle Transmission |
| Crankset |
E*Thirteen Helix Race Alloy
e*spec | Crank | 160mm | ISIS | 21.5mm Offset | w/Self Extractor | Black |
| Bottom Bracket |
|
| Cassette |
Sram X0 Eagle Transmission
10-52T |
| Chain |
Sram X0 Eagle Transmission |
| Pedals |
|
| Wheel (F) |
Race Face ERA eMTB Carbon |
Tuned Front-Specific Rim and Hub Design |
| Wheel (R) |
Race Face ERA eMTB Carbon |
Tuned Rear-Specific Rim and Hub Design |
| Hub (F) |
Race Face ERA eMTB | Vault 414J
Boost 15mm |
| Hub (R) |
Race Face ERA eMTB | Vault 424J
Boost 148mm |
| Spokes |
Race Face ERA eMTB | J-Bend |
| Rims |
Race Face ERA eMTB Carbon | 30mm
Width | 32H |
| Tires |
F: Maxxis DHX 2.5 3C MaxxGrip DD Tubeless Ready | R: Maxxis
Minion DHR II 2.5 3C MaxxTerra DD
Tubeless Ready |
| Seatpost |
OneUp V3 Dropper 31.6mm | SM = 150mm | MD = 180mm | LG = 210mm | XL
= 240mm |
| Saddle |
WTB Solano Fusion Form 142 |
Cromoly Rails |
| Accessories |
|
| Accessories |
|
| Accessories |
WTB TCS Tubeless Sealant |
| Accessories |
AXS Extension cord |
| Accessories |
|
| Accessories |
|
| Accessories |
|
| Drive
System |
Avinox M2S Drive System | 1300W Peak Power |130Nm (Boost)
Torque | 2.6kg system weight |
| Battery |
800 Wh Fully Integrated Premium Cell Li-Ion |
| Remote |
|
| Display |
AVINOX DP100, 2 inch OLED w/ Ambient Light sensor| Bluetooth
& ANT+|Anti=Theft| 65W Type-C port |
| Charger |
12 Ampere Power Output | 42V 508W Output|GaN fast
charging technology| Compatible with
600, 700, 800Wh Batteries| IPX3 |
