| Frame |
SMOOTHWALL™ Carbon | Integrated
Display | Smoothlink SL Flex Pivot| RIDE-4™ Adjustable Geometry |mullet
compatible| 150mm Travel | SMOOTHWALL™ Carbon | Smoothlink SL Flex Pivot
suspension| RIDE-4™ Adjustable Geometry |Mixed wheel flip chip| 150mm Travel Rear
Triangle |
| Fork |
RockShox Psylo Gold RC 160mm |
27.5 = 37mm Offset | 29 = 42mm Offset |
| Rear Shock |
Rock Shox Deluxe Select | Linear
XL Air Can | 210x55mm | Sealed Bearing Eyelet | 20x8mm F Hardware |
Size-Specific tune in FAQ |
| Headset |
FSA Orbit NO.85 Reach Adjust |
0mm Cups Installed | +/- 5mm Cups Included | 36°x45° Bearings | 30.2mm x 41mm
x 6.5mm Upper | 40mm x 51.8mm x 8.0mm Lower | 1.5" Crown Race |
| Stem |
Rocky Mountain 31.8 AM | 5° Rise
| All Sizes = 40mm |
| Handlebar |
Rocky Mountain AM |
780mm Width | 38mm Rise | 9° Backsweep | 5° Upsweep | 31.8 Clamp |
| Grips |
Rocky Mountain Lock On Ergo |
| Brakes |
Tektro HD-M5141 | Shimano Pad
Compatible |
| Rotors |
F: Tektro 203mm | R: Tektro
203mm |
| Brake Levers |
|
| Shifters |
Shimano CUES 10spd |
| Front Derailleur |
|
| Rear Derailleur |
Shimano CUES 10spd |
| Crankset |
Prowheel EB-16AVN | S - XL = 160mm| 34T Ring |
| Bottom Bracket |
|
| Cassette |
Shimano CUES 11-48T 10spd |
| Chain |
Shimano CNLG500 |
| Pedals |
|
| Wheel (F) |
|
| Wheel (R) |
|
| Hub (F) |
Shimano TC500 | 15mm Boost |
| Hub (R) |
Shimano TC500 Boost 148mm |
| Spokes |
2.0 Stainless |
| Rims |
Rocky Mountain TR30 | 32H |
| Tires |
F: Maxxis Minion DHF 2.5 EXO
Tubeless Ready | R: Maxxis Minion DHR II 2.4
EXO Tubeless Ready |
| Seatpost |
Tranz X +RAD1.0 Adjustable
Dropper Post | 30mm Adjustment | Alloy Clamp GL Lever | 31.6mm | SM = 150mm | MD = 170mm | LG - XL = 200mm |
| Saddle |
WTB Volt 142 | Steel Rails |
| Accessories |
|
| Accessories |
|
| Accessories |
WTB TCS Tubeless Sealant |
| Accessories |
|
| Accessories |
|
| Accessories |
|
| Accessories |
|
| Drive
System |
Avinox M2 Drive System | 1100W Peak Power |120Nm (Boost)
Torque | 2.7kg system weight |
| Battery |
700 Wh Fully Integrated Premium Cell Li-Ion |
| Remote |
|
| Display |
AVINOX DPC100, 2 inch OLED | Bluetooth | 65W Type-C port |
| Charger |
4 Ampere Power Output | 42V 168 W Output|Small size and light
weight | Compatible with 600, 700, 800Wh Batteries| IPX3 |
